ILX-705D alpine

Product beschrijving

The iLX-705D is the successor of the highly popular, award winning iLX-702D Digital Media Station. This new generation includes many improvements, such as much higher screen resolution, wireless Apple CarPlay, 2 USB ports, as well as a built-in Class-D amplifier and Hi-Res Audio capabilities.
If you look for a high-performance 2DIN system for your car that includes all the latest features, cutting-edge media compatibilities and killer sound quality, the iLX-705D is for you.
Enjoy wireless Apple CarPlay and Android Auto (wired) compatibility, DAB+ digital radio, USB video playback, Hi-Res Audio playback, Bluetooth hands-free and audio streaming and much more with this amazing Head Unit.
Bring exceptionally good sound quality into your vehicle: the Alpine iLX-705D is among the world’s first Head Units featuring a built-in Class-D amplifier and has a wide array of professional sound tuning functions, such as digital X-overs, a Parametric EQ, digital time correction and much more.
FEATURES Radio / DAB Tuner
Preset Stations (FM: 3x12 / DAB: 3x12 / AM: 2x12) Memory: Auto Memory Seek Mode: Local, DX, Pre-Set, Service RDS Functions: PI, PS, AF, TA, TP, PTY, NEWS, RADIO TEXT DAB+/DMB Supported DAB+ Slideshow Service DLS (Dynamic Label Service) DAB Service Following RDS Fallback (where available) Auto Ensemble/Service Memory Service Search Function PTY Search Function Alphabet Search Function BLUETOOTH®
Built-in BLUETOOTH® Module V4.2 HFP (Hands-Free Profile) Compatible A2DP (Advanced Audio Distribution Profile) Compatible AVRCP (Audio / Video Remote Control Profile) Ver.1.5 Compatible Phone Book Synchronization Speed Dial: 4 Preset Memory (per phone) Call History Display: Outgoing Calls / Incoming Calls / Missed Calls Redial Function Speech Volume Level Adjustment: (Outgoing and Incoming) 24 Menu Languages Microphone Included Works with iPhone®
Compatible with iPhones featuring a lightning connector Various search functions and Album Artwork Display Battery Charging Connectivity
Works with Apple CarPlay wirelessly (requires CarPlay enabled iPhone) Works with Android Auto (Requires Android Auto enabled smartphone, wired connection) Dash-Cam Link for DVR-C320S to allow playback and control of your dash-cam Navigation Function
Online navigation capability with Apple CarPlay and Android Auto compatible navigation apps Includes GPS enabled navigation antenna USB Media Connection
2x USB cable included USB port 1: data port / USB port 2: charging port Music Playback: FLAC, MP3, WMA, AAC, WAV, APE compatible Video Playback: MP4, MOV, FLV, MKV compatible Supported Video Coding: MPEG-4/H.264 (MPEG-4/AVC)/MPEG-1/MPEG-2 Various search functions included Sound Tuning
Bass Engine SQ and Bass Engine PRO sound tuning Subwoofer Level Adjustment 6 V PreOut 10 Equalizer PreSets 13-Channel Parametric EQ x4 audio channels + 4-channel for subwoofer 6-Channel Digital Time Correction 2-way Digital Crossover Independent Source Volume Level Setting For detailed sound tuning options please see the owner’s manual PDF below in the “SUPPORT” section General
4x 50 Watts Class-D High Power Amplifier 7-inch Capacitive Touch-Screen WXGA Display (1280 x 720p) Display angle adjustable after installation 3 PreOuts (6 V, Front / Rear / Subwoofer) 1 A/V AUX Input (3.5 mm micro jack) 1 HDMI input / 1 HDMI output 2 USB Ports (1x USB data port / 1x USB charging) Steering Wheel Remote Control Ready Vehicle Display Interface Ready (UART connection) Remote Control Ready 2x Camera Connection (Camera Direct connector) Note: does not support KCX-C250MC camera switch box Camera Distance Guides (adjustable) Live Contrast Adjustment Menu Language: 24 Languages Auto Dimmer Anti-theft security code Engine Start-Stop unaffected
SPECIFICATIONS
Screen
Screen Size: 7-inch Capacitive WXGA Number of Picture Elements: 2,764,800 pixels (1280 x 3 x 720) Illumination System: White LED Backlighting Effective Number of Picture Elements: 99.99% Colour System: NTSC, PAL Max Power Output Ratings
Max Power Output: 4x 50 W Radio / DAB Tuner
FM Tuning Range: 87.5 - 108.0 MHz AM Tuning Range: 531 - 1,602 kHz DAB band III: 174 – 240 MHz Alternate Channel Selectivity: 80 dB Signal-to-Noise Ratio: 65 dB / 90 dB DAB audio format: DAB/MPEG 2, DAB+/AAC, DMB Profile 1/BSAC/DMB profile 2/AAC WiFi
Reception Frequency: IEEE 802.11 B/g/n (2.4 GHz) Channels: 1 – 13 ch (2.4 GHz) Security Protocols: WPA3/WPA2-PSK (TKIP, AES) USB
USB Requirements: USB 2.0 USB 1: data port / 2,400 mA (Mass Storage Class) USB 2: charging port / 1,500 mA (CDP support) USB Class: Mass Storage Class, Play From Device File System: FAT16 / FAT32 / exFAT FLAC, MP3, WMA, AAC, WAV, APE Decoding Video Playback: MP4, MOV, FLV, MKV compatible Supported Video Coding: MPEG-4/H.264 (MPEG-4/AVC)/MPEG-1/MPEG-2 Number of Channels: 2-Channel (Stereo) Frequency Response: 5 - 40 kHz ±1 dB *Frequency Response may differ depending on the encoder software/bit rate Total Harmonic Distortion (at 1 kHz): 0.005% DynamicRange(at 1kHz): 95 dB Signal-to-Noise Ratio: 95 dB GPS
GPS compatible navigation antenna included GPS frequency: 1575.42 +/- 1.023 MHz Reception sensitivity (search): - 136 dB max BLUETOOTH®
BLUETOOTH® Version: Bluetooth V4.2 Output Power: +4 dBm Max. (Power class 2) HFP (Hands Free Profile) OPP (Object Push Profile) PBAP (Phone Book Access Profile) HSP (Head Set Profile) A2DP (Advanced Audio Distribution Profile) AVRCP (Audio/Video Remote Control Profile) SPP (Serial Port Profile) Supports LDAC Audio Codec Sound Tuning
Subwoofer Level Adjustment: 0 to +15 Subwoofer Phase Setting: 0° or 180° BASS ENGINE SQ: 5 Modes, Level 0 to +6 For detailed sound setting bands and frequencies please see the owner’s manual PDF below in the SUPPORT section HDMI Section
Input Format 720p / 480p / VGA General
Power Requirement: 14.4 V. DC (11-16V allowable) Pre Output Voltage (Before Clipping): 6 V / 10k ohms Dimensions
Weight: 1.4 kg Chassis Size (W x H x D) mm: 178 x 50 x 150 mm Display Size (W x H x D) mm: 171 x 96 x 18 mm
